Dillon Precision XL750 Reloading Machine

The XL750 is the next generation of the XL650, which has been in production since 1992. The shellplate indexing system has been completely redesigned so that the shellplate now turns more smoothly, decreasing case wobble. The index pawl has been relocated on the ring indexer and the spring direction reversed, this makes it more difficult to accidentally break the ring indexer. The index block now incorporates a roller which also aids in smoothing out the shellplate indexing process. The index block also incorporates a spring-loaded over-travel stop, which significantly increases the life of the springs on the machine.

The XL750 now has a simplified linear primer system, which only requires the removal of two nuts to detach the priming assembly from the machine, which significantly decreases the time required to change primer sizes.

All caliber conversions/caliber conversion parts and accessories (strong mount, bullet tray, roller handle, casefeeder etc.) for the XL650 are the same as is used on the XL750.

The XL750 is a new machine and it is not possible to upgrade an XL650 to an XL750.
